YC-80
AUCMA
| Model NO. | YC-80 | Climate Class | Sn |
| Cooling Type | Air Cooling | Refrigerant | Hc |
| Temp. Range [°c] | 2~8 | Controller | Microprocessor |
| Power Supply (V/Hz) | 220/50 | High/Low Temperature | Y |
| Sensor Error | Y | Capacity | 80 |
| Shelf (PC) | 3 | Power | 180 |
| Net Weight | 30.5kgs | Gross Weight | 34kgs |
| Transport Package | Container Load | Specification | Packing Dimension 530*595*910 |
| Trademark | Aucma | Origin | China |
| Production Capacity | 3000PCS/Month |
Temperature Control System
Microprocessor control system; digital display; display accuracy attains 0.1 degree.
Forced air cooling system; the inner temperature can stay at the range of 2 to 8 degree.
Security Control System
Multi malfunction alarms: high temperature alarm, low temperature alarm, sensor malfunction alarm, open the door alarm, power failure alarm (optional);
Three alarming methods: buzzer alarming, light flashing alarming and remote alarming is optional;
Protection function: power-on delay, time between stops.
Refrigeration System
International famous brand compressor;
Optimized evaporation system and condensation system;
Forced air cooling system; stable inner temperature .
Humanized Design
Safety door lock prevents arbitrary open;
Wide voltage design: it can work under 187V to 242V;
Hollow transparent tempered coated glass door can prevent door condensation;
LED lighting design; with a full display of contents inside freezer;
Multi-layer shelves, clearance can be adjusted as needed.
Silence
No condenser fan, low noise.
Refrigeration
Green fluoride-free refrigerant.
