| Quantity: | |
|---|---|
Autoclave could keep the temperature between 50~134℃, which is suitable for drug store, hospital, CDC and university. It could sterilize instrument, rubber, liquid, glass dish with a setting time of 4~120 mins.
lt is suitable for the sterilization ofequipment, dressings, rubber, liquidglassware, culture medium, waste andother items in medical and health andbiomedical research departments atall levels such as pharmaceuticals,food, universities, animal husbandry; disease control, and hospitals
Product advantages
Security: Multi-level protection, safe and reliable
· Door lock safety interlock device to ensure safety
· Automatic water shortage protection, and sound and light alarm, prevent dry burning
· Pressure safety protection, overtemperature and overpressure double protection
Intelligence: PID precise and intelligent control, easy to operate
· The PID temperature controller with digital display is adopted to realize precise tem-perature control
· Convenient operation, dynamic display, and detailed display of the current state in thesterilization process
Multiple modes: suitable for sterilization of different items
· Rapid cooling mode & natural cooling mode is suitable for the sterilization of differentitems
· Multiple procedure modes are suitable for sterilization of different items
Product dimensions
Product details
The upper cover cannot be opened under pressure, and the program cannot run until the upper cover is closed
Automatic protection for water shortage, and sound and light alarm
Self-expanding silicone rubber sealing ring has good sealing effect and long service life
Anti-hot design: the top cover is made of glass steel, safe and anti-hot protection
Product feature
· Automatic protection function: over-temperature protection, over-pressureventing protection
· After sterilization, the buzzer will remind and the machine will stop automatically
· Microcomputer automatic control, arbitrary set sterilization parameters
· Automatically discharge cold air and steam after sterilization
· Hand wheel translation type quick opening door structure
· Low water level protection to prevent dry burning
· High quality stainless steel material
· Equipped with standard test interface
· FRP door cover anti scald protection
· Stainless steel bucket (or net basket)
· Digital display, touch button
| Product Model | ALM-75 | |
| Nominal working pressure | 0.22MPa | |
| Rated Functioning Temperature | 134℃ | |
| Temperature Range | 50～134℃ | |
| Time Range | 4～120min | |
| Rated voltage/frequency | AC220V/50Hz | |
| Rated power | 4.5KW | |
| Net Capacity | 75L | |
| Sterilization chamber Dimension | ∅400X625 | |
| Internal Dimension | ∅380X540 | |
| Net Basket Dimension (optional) | ∅360X280X2 | |
| Net weight | KG | 90 |
| lbs | 198 | |
| Gross weight | KG | 120 |
| （lbs） | 264 | |
| （LXWXH）mm | 525X525X1200 | |
| Boundary Dimension | （LXWXH）In | 20X20X47 |
| （LXWXH）mm | 630X680X1290 | |
| Packing Dimension | （LXWXH）In | 25X27X51 |
| (20'/40'/40'H) | 27/54/108 | |
| Container Load | ||
| Interior material | SUS304 | |
| Cabinet Type | Vertical(Open up) | |
| Ambient Temperature | 5～40℃ | |
| Heating Type | Electric heating tube | |
| Cold Air Removal Method | Gravity displacement | |
| Water-Injection Method | Manual | |
| Drainage Method | Manual | |
| Door Opening Method | Handwheel horizontal opening | |
| Safety protection | Anti-dry burning, over-pressure protection,over-temperature protection, over-current protection, sensor disconnection detection. | |
| Sensor Type | PT100 | |
| Controller | Microcomputer | |
| Display Screen | LED | |
| Accessories details | Manual, tray, stainless steel inner tube, cover, vent tube | |
